Grant VORTEX Pro Combi 26e - Boiler Dimensions

8
Technical Data
Figure 2-1: Vortex Pro Combi Internal 21e and 26e dimensions
2.5 Boiler Dimensions
All dimensions in the diagram above are in millimetres.
2 Technical Data
Right Side View
Plan View
Left Side View
Rear View
External drain trap
exit (left hand)
Internal drain trap
exit (left hand)
high level
Internal drain trap
exit (left hand)
low level
108
227
441
19
98
35
190190 210
62
90
62
90
15
ø155
ø31
590
295
140
125 697
587
142
98
860
691
