3.2 Cleaning inside the machine 3 Daily cleaning
3.2 Cleaning inside the machine
11 Press STOP button (2).
22 Switch off at the main electrical switch.
Fig. 22 Removing spray pipe
Fig. 23 Cleaning of spray nozzle
33 Remove and check all 4 spray
pipes.
• The spray pipe lock is
folded up, then you push
the spray pipe up and pull
it to one side.
• The spray pipe is pulled
down gently and removed
from the machine.
• The spray pipe can now be
cleaned.
See Fig. 22 Removing spray
pipe
If any visible piece of e.g
chicken bone is seen in the
opening of the nozzle, please
take the back side of a tea-
spoon and carefully put the
piece back into the spray
pipe. Any pieces stuck will
then fall down the spray pipe
and out at the end.
See Fig. 23 Cleaning of spray
nozzle
Fig. 24 Tank grids
44 Lift out the overflow sieve (A).
Lift out the two tank grids.
Clean and flush with water.
See Fig. 24 Tank grids
Rev. 2021-11 33
