6 K2 Solo Media Server Accessories Installation Instructions 13 October 2009
Rack mounting
Rack mounting
This section provides instructions for the following field kit.
Tools and materials needed:
• Torx tool with T15 magnetic tip
1. Couple two K2 Solo Media Servers or one K2 Solo Media Server and one blank
rack
adapter as shown.
Upgrade Nomenclature Description
K2-SOLO-RACK Dual Rack Adapter for side by side mounting in standard
equipment rack
Attach side bracket
with 2 screws
1
Attach center bracket
with 3 side screws
2
Install 3 top screws
3
To Next Page
