5
SPECIFICATIONS
124V & 126V
Engine Briggs & Stratton
two cylinder, 4 cycle, air cooled
124V/48 126V/52 126V/61
Horsepower (G.I.H.P.) * 24 (17.9 kw) 26 (19.4 kw) 26 (19.4 kw)
Displacement 44.2 cu. in. (724 cc) 49.4 cu. in. (810 cc) 49.4 cu. in. (810 cc)
No-load r.p.m. 3600 3600 3600
Charging System 12VDC 16 amp. 12VDC 16 amp. 12VDC 16 amp.
negative ground negative ground negative ground
Starter Electric Electric Electric
Electrical System Safety interlocked Safety interlocked Safety interlocked
* Engine Manufacturer's Gross Hp Rating
Deck Drive Electric clutch
Drive System Dual path hydrostatic direct drive
Steering Dual levers independently control speed and direction of travel
Zero turning radius
Speed
124V/48 126V/52 126V/61
Forward (variable) 0-8mph (12.9km/h) 0-8mph (12.1km/h) 0-8mph (12.1km/h)
Reverse (variable) 0-6mph (9.6km/h) 0-6mph (9.6km/h) 0-6mph (9.6km/h)
Fuel Tank Capacity 6.5 U.S. gal. (24.6 l.)
Tire Sizes
124V/48 126V/52 126V/61
Drive Wheels - 4 ply rated 20 x 10 x 10 20 x 10 x 10 20 x 12 x 10
Front Wheels - 4 ply rated 13 x 6.5 x 6 rib 13 x 6.5 x 6 rib 13 x 6.5 x 6 rib
Dimensions of Tractor
124V/48 126V/52 126V/61
Seat Back Height 45" (1.14 m) 45" (1.14 m) 45" (1.14 m)
Seat Cushion Height 28" (0.71 m) 28" (0.71 m) 28" (0.71 m)
Tractor Width 44" (1.12 m) 44" (1.12 m) 49" (1.24 m)
Tractor Length 75" (1.91 m) 75" (1.91 m) 78" (1.98 m)
Wheel Base 45" (1.14 m) 45" (1.14 m) 48" (1.22 m)
Weight - Uncrated 810 lbs (367 kg) 830 lbs (376 kg) 880 lbs (400 kg)
Weight - Crated 1060 lbs (481 kg) 1080 lbs (490 kg) 1130 lbs (512 kg)
Hour Meter Standard
