Page 11
Disconnect The Power Plug
This is the plug that carries
power from the rear to the
front of the buggy.
It is located at the bottom left side near the
foot tray or between the batteries.
There are two types of plug. One simply pulls away
from the socket, there is a locating grove to ensure
correct pin alignment on re-assembly. The other type of
plug requires twisting a locking sleeve then pulling
apart, again a grove ensures correct pin alignment
Dismantle The Chassis
To separate the vehicle in
two, pull up the spring
loaded plunger (located at
the centre of the vehicle)
and pull the front section
from the rear.
The steering column can be lowered ready
for placing into a vehicle. The
components of the buggy are heavy and
care with posture should be taken when
lifting – where possible ask for assistance.
