Taxi mode
Info
Programs can be replaced via the IR interface using a taxxi
module. For this purpose, the device must be in TAXIMODE and
must be energised.
TAXIMODE can be ended via ESC.
taxxi module
prog =program selection
in =import program
out = export program
· Use prog to select a program number.
·Press in or out depending on whether a
program is to be imported or exported.
· Hold taxxi module vertically above the
IR interface.
·Pressing in or out again starts the transfer.
· Er2 indicates that problems occurred during
the transfer. Go back by pressing prog.
