9 10
①
ESC Configure Socket
④ DC Input
⑦
3.0”TFT LCD W/Touch Screen
⑩
Charge / Discharge Status LED Bar
⑬
Temperature Sensor Port
Cooling Fan
② Mini USB
⑤ AC Input
(100 ~ 240V)
⑧
LED Indicator for Charge / Discharge
⑪
Output of the Charger
⑭
Output (12V)
③ Cooling Fan
⑥ Power Switch
⑨
Channel Selection Button (CH1/CH2)
⑫
Balance Port
⑮
USB Output Socket (+5V 1.0A)
②
①
⑦
⑧
⑨
⑩
⑪
⑭
⑮
⑫
⑬
④
⑤
⑥
③
TOP FRONTBACK RIGHT
◎ CHARGER CONTROL IDENTIFICATION
