GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
Modifications reserved. No liability for printing errors 11/2011
3
Notes on building the model
• Before you start building the aircraft it is essential to study the plan and read right
through the instructions. Please bear in mind the dangers inherent in the handling
of tools.
• When preparing wiring, be sure to use cable capable of carrying the currents likely
to flow when the model is flying.
• Deploy the receiver aerial as far away as possible from high-current cables (at
least 3 cm).
• Remove all traces of grease from the joint surfaces of components which are to be
glued. A good method is to sand lightly before wiping with a non-greasy liquid
detergent solution. The same applies to surfaces which are to be painted,
otherwise the paint will not adhere permanently. Before gluing any GRP parts, and
GRP fuselages in particular, the joint surfaces must be sanded thoroughly with
fine-grit abrasive paper before de-greasing with a solvent such as acetone. This is
the only method of obtaining durable glued joints involving GRP parts.
Additional items required
Glowplug engine / petrol engine and accessories
Recommended internal-combustion engine
Engine
Order No.
Capacity
cc
Silencer
Order No.
Propeller
Order No.
OS MAX FS 200 S
2728
32.4
Included
1318.45.25
Petrol engine GT 33
2772
33
Included
1318.45.25
1318.50.25
Recommended electric motor
Electric motor
Order No.
Propeller
Order No.
Flight battery
Order No.
Speed
controller
Order No.
COMPACT
630
7725
55 x 25 cm
1326.22x10
LiPo V-MAXX 45C
5/4200 18,5 V/4,2 Ah
9740.5
Two required
COMPACT
CONTROL
80 HV
7228
Radio control system
The RC system must feature at least five control functions, with ten servos.
The transmitter should also include a servo reverse facility.
