Gravely 1138 - Page 14

3.
4.
5.
Depress Clutch
Perlal,
place
Gear Selector
Lever ancl
Hi-Lo Range Selector
into the desired
gear
and
rarige anC
slowly release
the
pedal
to
provide
smooth
acce
lerat io n
"
Select the
desired
threttle speed with
the Throttle-
Choke Control
Lever.
WLren operat-inq a
power-driven
attachment,
operat.e
the engine
at
f ull throttle,
(3254
RPIVI
)
unless
otherwise
specif ied and control
travel speed
by
selecting
an appropriate
gear.
To
raise or lower
the
attachment use
the Attachment
I'if,t
Lever.
To start the
attachment,
engaqe the
PTO
Control
slowly
with the engine
running
at l/2
throttle, then
increase
speed to
ful1 throttle.
To
stop
the
tractor,
fully
depress
Clutch
and
Brake
Pedals
and
place
Gear Selector
Lever in
"NEUTRAL".
Ful1y depress
Brake
Pecial and engage the
Parkinq Brake
Lock when
parking
or leaving the tractor.
(See
Fiqure
2
and 3).
NOTE:
Do
not
force
Gear
Selector Lever if
qear
does not
enqaqe.
Apply slight
pressure
on the
Gear
Selector Lever
while
releasinq
the
Clutch
Peda1.
The Clutch
Pedal must be depressed to enqage any
selected
qear,
Depressing
the
pedal
too
1itt1e
will cause
gear
clash and
possible
damage to the
transmission.
Hold lever toward
enoaqed
position
while
declutching.
6.
7.
3.s Operating
Tips:
NOTE: operate
engine
at
"FAST"
throttle
settinq
and
select
Gear
Selector
Lever as
described in
fo1 lowing instructions.
I.
The
tractor may
be operated
at one
of three forward
speeds
or one
reverse speed
in each
of two speed
ranges.
Depress Clutch
Pedal and use Gear
Selector
Lever
to
shift
from
I'NEUTP,AL"
(N)
to
First Speed
(1)
or
Reverse
(R).
The operator should
acquaint
himself
with
the area to
be
mowed and slow
down
using
Gear Selector
Lever,
not
CIutch,
to
maintain
control
in restricted
spaces.
2.
ilrl
