ZT XL™
Owner/Operator Manual
Manuel Du Propriétaire/Utilisateur
Models
915160 – 42 ZT XL
(Serial No. 010000 and up)
915162 – 48 ZT XL
(Serial No. 010000 and up)
915164 – 54 ZT XL
(Serial No. 010000 and up)
04052400A 1/12
Printed in USA
ENGLISH
FRANÇAIS
Gasoline containing up to 10% ethanol (E10) or up to 10% MTBE (methyl tertiary butyl ether) is
acceptable for use in this machine.The use of any gasoline exceeding 10% ethanol (E10) or
10% MTBE will void the product warranty.
Il est possible d’utiliser de l’essence contenant jusqu’à 10% d’éthanol (E10) ou 10% de MTBE
(éther méthyl-tertiobutylique) sur cette machine.L’utilisation d’une essence contenant plus de
10% d’éthanol (E10) ou de 10% de MTBE annulent la garantie.

Table of Contents

Questions and Answers

  • M
    Matthew Manning PhDAug 16, 2025
    Why my Gravely Lawn Mower engine will not crank/start?
    • C
      Cindy SmithAug 16, 2025
      If your Gravely Lawn Mower engine won't crank or start, several factors could be at play. First, make sure the safety interlock system is properly engaged and not faulty. Next, ensure the fuel tanks are filled. A discharged battery could also be the culprit, so try charging it. Check for poor connections between the battery and cables, tightening or cleaning them as necessary. Inspect the spark plug wires and plugs, connecting any loose wires or replacing faulty plugs. If these steps don't resolve the issue, there may be a fault in the electrical system or the engine itself, and you should contact your Gravely Dealer.
  • M
    mckinneyallisonAug 19, 2025
    What to do if PTO or mower blades do not engage or shuts off on my Gravely 915162?
    • A
      agonzalezAug 19, 2025
      If the PTO or mower blades on your Gravely Lawn Mower won't engage or shut off, it could be due to several reasons. Ensure the operator presence switch is depressed by sitting on the seat. A loose or disconnected electric clutch connector can also cause this issue; check and connect it. Additionally, inspect the PTO belt for faults and replace if necessary. If these steps don't resolve the issue, the operator presence switch, PTO switch, wires, connectors, or clutch may be faulty, and you should contact your Gravely Dealer.
  • C
    Chad FosterAug 22, 2025
    What to do if my Gravely Lawn Mower does not move with engine running when using steering levers?
    • R
      Ruth HamiltonAug 22, 2025
      If your Gravely Lawn Mower doesn't move when using the steering levers while the engine is running, first check if the transmission bypass lever is engaged and disengage it. If that's not the issue, the hydrostatic belt might be faulty and needs replacement. If problems persist, the transmission itself may be faulty, and you should contact your Gravely Dealer.
  • M
    Michael ThomasAug 25, 2025
    What to do if my Gravely 915162 moves with engine off and parking brake engaged?
    • R
      Rebecca CabreraAug 26, 2025
      If your Gravely Lawn Mower moves with the engine off and the parking brake engaged, the parking brake likely needs adjustment or is faulty. Contact your Gravely Dealer for assistance.
  • R
    Randall SteinAug 28, 2025
    How to fix a Gravely 915162 Lawn Mower when the engine runs rough?
    • D
      Dustin JohnsonAug 28, 2025
      If your Gravely Lawn Mower engine is running rough, try disengaging the choke. Also, the air filter cartridge might be plugged, so clean or replace it. If the problem persists, the engine may be faulty, and you should contact your Gravely Dealer.
  • B
    Bruce SmithAug 30, 2025
    What causes a Gravely Lawn Mower engine to overheat?
    • C
      Cynthia GarciaAug 30, 2025
      If your Gravely Lawn Mower engine overheats, first check the engine oil level and add oil if it's low. Also, the cooling system might be plugged, so clean it. If the issue continues, the engine itself may be faulty, and you should contact your Gravely Dealer.
  • R
    Rodney WrightSep 2, 2025
    How to improve the cutting quality of my Gravely 915162 Lawn Mower?
    • C
      Carol LoweSep 3, 2025
      If you notice poor cutting quality with your Gravely Lawn Mower, it might be due to the mower deck not being level or the mower pitch being incorrect; level and adjust it accordingly. Also, check if the mower blades are dull or faulty; sharpen or replace them as needed.
  • C
    Catherine BarrettSep 6, 2025
    Why my Gravely Lawn Mower does not travel in a straight line?
    • A
      anashSep 6, 2025
      If your Gravely Lawn Mower isn't traveling in a straight line, start by checking the tire pressure. Also, the steering levers may need adjustment. If the problem persists, the hydrostatic transmission and/or linkage may need adjustment, and you should contact your Gravely Dealer.
  • R
    Rachel SmithSep 9, 2025
    Why my Gravely Lawn Mower creeps with steering levers in neutral position?
    • D
      Derek MoraSep 9, 2025
      If your Gravely Lawn Mower creeps with the steering levers in the neutral position, the hydrostatic transmission and/or linkage likely needs adjustment. Contact your Gravely Dealer for assistance.
  • A
    andreafosterSep 12, 2025
    Why does the hour meter continue when engine not running on my Gravely Lawn Mower?
    • D
      Dr. Janet Smith DVMSep 12, 2025
      If the hour meter on your Gravely Lawn Mower continues to run when the engine is off, it's likely because the ignition key is in the run position. Turn the ignition key to the off position to resolve this.

Summary

SAFETY FUNDAMENTALS

SAFETY ALERT SYMBOLS AND NOTATIONS

Understanding danger, warning, caution symbols and general notations.

SAFETY DECALS AND LOCATIONS

OPERATIONAL HAZARDS

Covers discharge, dismemberment, tipping, and hot surface hazards.

GENERAL SAFETY RULES

Essential rules for safe operation, maintenance, and transport.

ASSEMBLY AND CONTROLS

UNIT ASSEMBLY PROCEDURES

CONTROLS AND FEATURES

OPERATING THE MOWER

STARTING AND OPERATING PROCEDURES

How to start, run, and stop the mower using its controls.

FUELING AND EMERGENCY STOPS

Proper fueling, emergency stops, and moving the unit manually.

MAINTENANCE AND SERVICE

MAINTENANCE SCHEDULE AND CHECKS

SERVICE AND ADJUSTMENTS

BATTERY AND HYDRAULIC SERVICE

STORAGE AND TROUBLESHOOTING

SOLVING COMMON PROBLEMS

Troubleshooting guide for engine, transmission, and operational issues.

Gravely 915162 Specifications

General IconGeneral
Model915162
Cutting Width52 inches
Deck TypeFabricated
Turning Radius18 inches
EngineKohler CH740
Engine Power23 HP
