9 - 34
Pro 200 Walk-Behind Kohler Engine
NOTES: NORMALLY OPEN SWITCHES. MANUALLY ACTIVATED. CONTACT RESISTANCE IS 0.1 - 0.3 OHMS
RESISTANCE.
NOTES: NORMALLY OPEN SWITCH. LARGE CONTACTS ARE 3 TO 5 OHMS RESISTANCE. SMALL
TERMINALS 0.1 TO 0.3 OHMS.
Ignition Switch Off Run Start
Red (B) 12.00 12.00 12.00
Brown (S) 12.00
Pink (A) 12.00 12.00
Red/White (M) Connected to kill (magneto) circuit to ground
Left and Right Presence Switch Off Run Start
Brown 12.00
White (When activated) 12.00 to ground
Hourmeter Off Run Start
Pink 12.00 12.00
White 12.00 12.00
Solenoid Off Run Start
Triple Red 12.00 12.00 12.00
Red (starter input) 12.00
Brown (input lead) 12.00
Brown and Yellow (output) 12.00
Interlock Module Off Run Start
Red Connected to engine ground for engine kill
Yellow 12.00 12.00
Brown 12.00 12.00
