Gravely 992235 - CONTROLS AND FEATURES OVERVIEW; Component Identification; Key Control Functions

EN - 15
1. Fuel Tanks and Caps
2. Steering Levers
3. Hydraulic Oil Reservoirs
4. Ignition Switch
5. Hour Meter
6.
Throttle Lever
7. Choke Control Lever
(992230, 234, 235, 239, 244, 245)
8. Power Take Off (PTO) Switch
9. Battery
10. Fuel Control Lever
11. Mower Lift Pedal
12. Mower Deck
13. Transport Lock Lever
14. Seat Adjustment Lever
15. Seat Height/Pressure Adjustment Knob
16. Parking Brake Lever
17. Transaxle Bypass Valve
18. Oil Pressure Light
19. Height-of-Cut (HOC) Index Wheel
20. Malfunction Indicator Light
(992224, 225, 231, 233)
21. Roll-Over Protection Structure (ROPS)
CONTROLS AND FEATURES
1
2
3
9
10
11
12
13
14
7
6
5
18
8
4
17
Figure 4
16
19
21
20
15
