Operator’s Manual

Manuel de I’utilisateur

Compact-Pro

34

05092100B • 12/16

Printed in USA

ENGLISH

FRANÇAIS

E10

Models

991088 – Compact Pro 34

(SN 060,000 +)

991105 – Compact Pro 34 CARB

(SN 060,000 +)

™

Table of Contents

Questions and Answers:

J
Joshua GonzalezAug 14, 2025
Why won't my Gravely Compact-Pro 34 991088 engine start?
- S
  Stephanie DunnAug 14, 2025
  Your Gravely Lawn Mower engine may not start due to several reasons. The safety interlock system may not be engaged or could be faulty, the fuel tank might be empty, or the fuel supply could be contaminated. Other potential causes include a discharged battery, poor connection between the battery and cables, loose spark plug wires, or faulty spark plugs. In this case you should check the safety interlock system, fill the fuel tank, replace with clean fuel, charge the battery, tighten or clean the battery and cables, or connect or replace the spark plug wires.
P
Patrick ThompsonAug 18, 2025
Why my Gravely Compact-Pro 34 991088 Lawn Mower unit does not track straight?
- B
  bhumphreyAug 18, 2025
  If your Gravely Lawn Mower isn't tracking straight, it could be due to incorrect tire pressure or steering levers needing adjustment. Check the tire pressure or adjust the steering levers.
L
lisahullAug 21, 2025
What to do if my Gravely Compact-Pro 34 991088 unit does not drive?
- M
  Michael HigginsAug 21, 2025
  If your Gravely Lawn Mower isn't moving, it could be due to a few reasons: the hydraulic bypass valve might be open, the parking brake could be engaged, or the hydraulic oil level might be low. Make sure to close the bypass valves, disengage the parking brake, and add hydraulic oil.
J
Jonathan GatesAug 25, 2025
Why does my Gravely Lawn Mower engine run rough?
- D
  David TuckerAug 26, 2025
  A rough-running engine on your Gravely Lawn Mower can be caused by a few things. The choke control knob might be in the 'on' position, or the air filter cartridge could be plugged. Try moving the choke knob to the 'off' position, or cleaning/replacing the air filter cartridge.
J
Jennifer DavisAug 28, 2025
What causes poor cutting quality in a Gravely Compact-Pro 34 991088?
- E
  Emily MarshallAug 28, 2025
  Poor cutting quality with your Gravely Lawn Mower can stem from several issues: the mower blades might not be level, or the mower deck pitch could be incorrect. The blades could also be dull or faulty, the mowing speed might be too fast, the belt tension or condition could be poor, or the cutting height might be too low. In this case you should level and adjust the pitch of the mower deck, sharpen or replace the mower blades, drive slower when cutting grass, replace the deck drive belt, or avoid setting the cutting height too low.
R
Reginald BallardSep 1, 2025
What to do if Gravely Lawn Mower PTO malfunctions?
- E
  erinwashingtonSep 1, 2025
  If the PTO on your Gravely Lawn Mower is malfunctioning, it might be because the operator presence switch is not engaged or the deck drive belt is faulty. To resolve this, ensure you are sitting on the operator seat to activate the switch or replace the deck drive belt.
D
donna89Sep 5, 2025
Why does my Gravely Compact-Pro 34 991088 engine overheat?
- J
  Jeffrey CollinsSep 5, 2025
  Your Gravely Lawn Mower engine overheating could be due to low engine oil level or plugged cooling fins. Add engine oil or clean the engine.
D
David FriedmanSep 9, 2025
What to do if my Gravely Compact-Pro 34 991088 moves with the engine off and parking brake engaged?
- A
  anthonycampbellSep 9, 2025
  If your Gravely Lawn Mower moves when the engine is off and the parking brake is engaged, the parking brake likely needs adjustment. Adjust the parking brake lever.

Gravely Compact-Pro 34 991088 Specifications

General

Engine Displacement	726 cc
Cutting Width	34 inches
Cutting Height	1.5 - 4.5 inches
Deck Material	10-gauge steel
Transmission	Hydro-Gear ZT-2800

Summary

Safety Guidelines and Symbols

Detailed Safety Decal Explanations

Hazard Warnings (Danger, Amputation, Discharge)

Covers DANGER levels, amputation risks, and safe discharge practices.

Tipping, Service, and Bystander Hazards

Guidance on avoiding tipping, safe servicing, and bystander safety.

More Safety Decal Information

Loss of Traction and Additional Dangers

Instructions for loss of traction and further DANGER warnings.

Operational Safety Rules

Operator Training, Age, and Hot Surfaces

Key training, age limits, and warnings about hot parts and rotating components.

Safe Operating Practices

Pre-Operation Checks

Essential checks and maintenance before starting the unit.

Operation Precautions

General Operation and Slope Safety

Rules for safe operation, including slopes and general controls.

Parking, Fuel, Towing, and Battery Safety

Fuel Handling and Storage

Precautions for handling gasoline, ethanol blends, and fuel storage.

Towing, Accessories, and Battery Safety

Guidelines for towing, accessories, and battery handling.

Service, Transport, and Battery Safety

Service and Transport Safety

Safety precautions for maintenance, service, and transporting the unit.

Controls and Features Overview

Control Identification Diagram

Control Operations

Ignition, Fuel, PTO, Choke, Throttle, and Meter

Operating Controls and Procedures

Parking Brake, Interlocks, and Steering

Starting and Pre-Operation Checks

Unit Operation and Mowing

Mowing Operation and Best Results

Maintenance Schedule

Scheduled Maintenance Tasks by Hours

Steering System Adjustments

Neutral Steering Control Adjustment

Procedure for adjusting the steering system to ensure neutral control.

Tracking and Brake Adjustments

Adjusting Unit Tracking

How to adjust the unit so it travels in a straight line.

Parking Brake Lever Adjustment

Mower Deck Leveling and Pitching

Leveling the Mower Deck

Procedure for leveling the mower deck side-to-side for optimal cutting.

Setting Mower Blade Pitch

Instructions for setting the front-to-back pitch of the mower blades.

Clutch Adjustment and Storage Preparation

Clutch Engagement Adjustment

How to check and adjust the clutch air gap for proper engagement.

Troubleshooting Common Issues

Engine Starting and Running Problems

Drive and PTO Malfunctions

Troubleshooting Cutting Performance

Poor Cutting Quality Solutions

Technical Specifications

Model and Performance Specifications

Detailed technical specifications for different models, including dimensions and performance.

Commercial Mowing Equipment Warranty

Warranty Coverage and Extensions

Warranty Limitations and Customer Duties

Warranty Exclusions and Responsibilities

Details on warranty exclusions, limitations, and customer responsibilities.

Warranty Policies and Legal Disclaimers

Regional Policies and Damage Limitations
