GB - 10
Connect Battery
Connect negative (–) battery cable to battery
(see Replace Battery on page 20 and
perform steps 2 through 3 in the installation
section).
Check Engine Oil
Refer to Engine Manual.
Check Hydraulic Oil
See HYDRAULIC FLUID on page 18.
Fill Fuel Tank
See FILLING FUEL TANK on page 13.
Hardware
Check for loose hardware.
Check Safety Interlock System
See Safety Interlock System on page 11.
Check Blade Level and Blade Pitch
See Leveling the Mower Deck on page 27.
Check Function of All Controls
Ensure unit runs and performs properly.
WARNING: Safety interlock
system failure and improper
operation of unit can result in
death or serious injury. Test this
system each time unit is
operated. If this system does not
function as described, do not
operate until repairs are made.
WARNING: FAILURE OF
CONTROLS could result in death
or serious injury.
CONTROLS AND FEATURES
1. Choke Control
2. Throttle Lever
3. Seat Knob
4. Fuel Tanks and
Caps
5. Steering Levers
6. Fuel Shut Off Valve
7. Mower Deck with
Chute Deflector
8. Height of Cut
Indicator
9. Foot Board Latch
10. Mower Lift Pedal
11. Mower Lift Lock
12. Parking Brake
13. Seat Adjustment
Lever
14. Power Take Off
(PTO) Switch
15. Ignition Switch
16. Oil Pressure
Indicator
17. Hour Meter
Figure 4
OF3312
1
2
5
6
7
8
9
12
13
3
14
15
4
17
16
10
11
