1" = 25.4mm (conversion factor)
Replacement parts for the Great Planes “Ultimate” ARF
are available using the order numbers in the
Replacement Parts List that follows. The fastest, most
economical service can be provided by your hobby
dealer or mail-order company.
To locate a hobby dealer, visit the Hobbico web site at
www.hobbico.com. Choose “Where to Buy” at the bottom of the
menu on the left side of the page.Follow the instructions provided
on the page to locate a U.S., Canadian or International dealer. If a
hobby shop is not available, replacement parts may also be
ordered from Tower Hobbies
®
at www.towerhobbies.com, or by
calling toll free (800) 637-6050.
Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721,
but full retail prices and shipping and handling charges will
apply. Illinois and Nevada residents will also be charged
sales tax. If ordering via fax, include a Visa
®
or MasterCard
®
number and expiration date for payment.
Mail parts orders and payments by personal check to:
Hobby Services
3002 N. Apollo Drive, Suite 1
Champaign, IL 61822
Be certain to specify the order number exactly as listed in
the Replacement Parts List. Payment by credit card or
personal check only; no C.O.D.
If additional assistance is required for any reason, contact Product
Support by e-mail at productsupport@greatplanes.com, or by
telephone at (217) 398-8970.
Replacement Parts List
Order Number Description How to Purchase
Missing pieces Contact Product Support
Instruction manual Contact Product Support
Full-size plans Not available
GPMA2830 Bottom Wing Set Contact Hobby Supplier
GPMA2831 Top Wing Set Contact Hobby Supplier
GPMA2832 Fuselage Set Contact Hobby Supplier
GPMA2833 Tail Set Contact Hobby Supplier
GPMA2834 Cowl Contact Hobby Supplier
GPMA2835 Landing Gear Contact Hobby Supplier
GPMA2836 Wheel Pants (2) Contact Hobby Supplier
GPMA2837 Canopy Contact Hobby Supplier
GPMA2838 Tail Wheel Assembly Contact Hobby Supplier
GPMA2839 Aluminum Spinner Contact Hobby Supplier
GPMA2840 Interplane Struts (2) Contact Hobby Supplier
GPMA2841 Interplane Thumb Screws (4) Contact Hobby Supplier
GPMA2842 Cabane Struts (2) Contact Hobby Supplier
GPMA2843 Decal Set Contact Hobby Supplier
GPMA2844 Flying Wire Set Contact Hobby Supplier
Fuse = Fuselage
Stab = Horizontal Stabilizer
Fin = Vertical Fin
LE = Leading Edge
TE = Trailing Edge
LG = Landing Gear
Ply = Plywood
" = Inches
mm = Millimeters
SHCS = Socket-Head Cap Screw
COMMON ABBREVIATIONS
ORDERING REPLACEMENT PARTS
METRIC CONVERSIONS
5
1/64" = .4 mm
1/32" = .8 mm
1/16" = 1.6 mm
3/32" = 2.4 mm
1/8" = 3.2 mm
5/32" = 4.0 mm
3/16" = 4.8 mm
1/4" = 6.4 mm
3/8" = 9.5 mm
1/2" = 12.7 mm
5/8" = 15.9 mm
3/4" = 19.0 mm
1" = 25.4 mm
2" = 50.8 mm
3" = 76.2 mm
6" = 152.4 mm
12" = 304.8 mm
18" = 457.2 mm
21" = 533.4 mm
24" = 609.6 mm
30" = 762.0 mm
36" = 914.4 mm
