Duct Type Split Air Conditioner
Service Manual
Parts List:
No. Names Material code Qty.
1 Bottom Cover Assy 01265357 1
2 Hook 02112466 4
3 Right Side Plate 1 01315378 1
4 airproof Panel 1 01345218 1
5 Water Tray Panel Assy 01285283 1
6 Evaporator Bottom side 01095271 1
7 Evaporator Assy 01025356 1
8 Seal of Connection Pipe Plate 01495241 1
9 Right Side Plate 2 01315370 1
10 Evaporator top side 01095270 1
11 Evaporator Back side 01095272 1
12 Top Cover Assy 01265359 1
13 air lter Panel 02285220 2
14 air lter 11725211 2
15 Left Side Plate 2 01315367 1
16 airproof Panel 2 01345219 1
17 Left Side Plate 1 01315376 1
18 Fan (left) SYP-250/190J-1 15705306 1
19 Motor FG1200A 15705229 1
20 Fan (right) SYP-250/190J-1 15705307 1
21 Motor support Plate 01805381 1
22 Fan Fixed Plate 01325325 1
23 Front Side Plate 01315373 1
24 temp.sensor (15K) 3900012123 1
25 temp.sensor (20K) 3900012121 1
26 Display board Z4E351A 30294219 1
27 Electric Box 01395679 1
28 Main PCB Z4E35A 30224056 1
29 Original PCB Mounting Plate Sub-Assy 01845221 1
30 AC Contactor LC1D12M7C 44010232 1
31 Terminal Board (5 unit) 42010194 1
32 Isolation Washer 70410503 2
33 Wire Clamp 71010102 1
34 Wire Clamp 02141009 1
35 Terminal Board (2 unit) 420101851 1
36 Transformer 54X25C 43110239 1
