Duct Type Split Air Conditioner
Service Manual
5 Isolation Plate 01245248 1
6 Inhalation Tube Sub-Assy 04675410 1
7 4-way Valve Sub-Assy 04145324 1
8 electromagnetism loop 430004008 1
9 Chassis Sub-assy 01195239P 1
10 Valve Support 01715001 1
11 Gas-liquid Separator 07228767 1
12 Gas-liquid Separator nip 02264107 1
13 Back Side Plate Sub-Assy 01314207P 1
14 Handle 26235253 2
15 Top Cover 01258730 1
16 Electric Box Cover 01264157 1
17 Electric Box 01395676 1
18 Motor support Plate 01804174 1
19 Protection Grill 01574101 1
20 sponge 12204705 1
21 temp.sensor (20K) 390001923 1
22 temp.sensor (15K) 390002063 1
23 Condenser Sub-Assy 01125354 1
24 xation Plate 01845227 1
25 Motor LW92E 15705701 2
26 Axial Flow Fan 10338701 2
27 Streamlined Dome 2 26904120 2
28 Grill 26904119 2
29 Left Side Plate 01314163P 1
30 Front Plate 01514101P 1
31 Front Side Plate 01314205P 1
32 temp.sensor (50K) 3900012129 1
33 Discharge Tube Sub-Assy 1 04635732 1
34 Discharge Tube Sub-Assy 04635409 1
35 Over Current Protector UO-10-16A/16A 46020103 1
36 Plastic nip 71011021 4
37 Main PCB ZS401D 30224211 1
38 Transformer SC28B2 43110171 1
39 Original PCB Mounting Plate Sub-Assy 01845323 1
40 Main PCB WZ4E35 30224058 1
41 Terminal Board (2 unit) 42011103 2
42 Capcaitor CBB61 4uF 500V 33010013 2
43 AC Contactor LC1D25M7C 44010213 1
44 Terminal Board T480C 42011043 1
45 Isolation Washer 70410503 2
46 Wire Clamp 71010102 1
47 Wire Clamp 02141009 1
48 Terminal Board (2 unit) 420101851 1
49 Phase Reverse Protector (380V) 46020052 1
