Gree FP-136WM-D Service Manual

41
Floor Ceiling Type Fan
Coil Unit Service Manual
No.
Discription
FP-68WM-K FP-85WM-K FP-102WM-K
QuantityEM51700020 EM51700050 EM51700060
Name of Part Part Code Part Code Part Code
1 Left Decoration Plate 261124172 261124172 261124172 1
2 Shaft of Louver 10512025 10512025 10512025 2
3 Guide Louver Bracket 2690601702 2690601702 2690601702 3
4 Guide Louver Fixed Mount 24222016 24222016 24222016 2
5 Shaft of Louver 10512026 10512026 10512026 2
6 Guide Louver 105124042 105124042 105124042 1
7 Right Decoration Plate 261124212 261124212 261124212 1
8 Left Mounting Plate of Swing Motor 26152007 26152007 26152007 1
9 Panel Sub-assy 01532414 01532414 01532414 1
10 Mounting Box Sub-Assy 201020411 201020411 201020411 1
11 Display Board 30546106 30546106 30546106 1
12 Button Panel Sub-Assy 201620041 201620041 201620041 1
13 Right Mounting Plate of Swing Motor 26152008 26152008 26152008 1
14 Stepping Motor 15212402 15212402 15212402 2
15 Press Plate of Swing Motor 26112026 26112026 26112026 2
16 Water Tray Component 0127241402 0127241402 0127241402 1
17 Pipe Hoop 70812001 70812001 70812001 1
18 Drain Pipe Sub-Assy 05235433 05235433 05235433 1
19 Handle 26232001 26232001 26232001 4
20 Foam Sub-assy of Right Side Plate 12312407 12312407 12312407 1
21 Mounting Plate 01332404 01332404 01332404 1
22 Decorative Board 26112033 26112033 26112033 1
23 Mounting Plate Sub-assy 01847503 01847503 01847503 1
24 Electric Box Sub-Assy 01403242 01403242 01403242 1
25 Press Wire Holder 24253001 24253001 24253001 1
26 Press Wire Board 24253002 24253002 24253002 1
27 Terminal Board 42010178 42010178 42010178 1
28 Protective Tube 46010013 46010013 46010013 1
29 Main Board 30036052 30036052 30036052 1
30 Transformer 43110237 43110237 43110237 1
31 Electric Box Cover 01413008 01413008 01413008 1
32 Centifugal Fan 10312401 10312401 10312401 4
33 Capacitor 33010027 33010027 33010027 1
34 Motor 15012406 15012406 15012406 1
35 Axletree 73012403 73012403 73012403 2
36 Front propeller housing 22202031 22202031 22202031 4
37 Rear propeller housing 22202032 22202032 22202032 4
38 Rear Side Plate Sub-assy 01302418 01302418 01302418 1
39 Motor Support Sub-assy 01702401 01702401 01702401 1
40 Filter Sub-assy 11122012 11122012 11122012 1
41 Panel Grille 22412011 22412011 22412011 1
42 Panel Grille Buckle 2 26252003 26252003 26252003 2
43 Remote Control 305125063 305125063 305125063 1
44 Cooling coil assy 0112612001 0112612001 0112612001 1
45 Panel Grille Buckle 1 26252002 26252002 26252002 2
46 Environment Sensor 39000186 39000186 39000186 1
47 Water-leading board assy 1362401 1362401 1362401 1
48 Cover Plate Of Evaporator 01072417 01072417 01072417 1
49 Left Decorative Board 26112032 26112032 26112032 1
50 Left Mounting Plate 01332405 01332405 01332405 1
51 Foam Sub-assy of Left Side Plate 12312406 12312406 12312406 1
Above data is subject to change without notice,please refer the SP in global service website.
