Floor Ceiling Type Fan
Coil Unit Service Manual
FP-34ZD-K; FP-51ZD-K; FP-68ZD-K; FP-85ZD-K; FP-102ZD-K; FP-136ZD-K; FP-170ZD-K; FP-204ZD-K.
5 Disassembly of key spare part
5�1 replace motor
Operation step Sketch
①.
Open panel grille
Press the panel grille clamps.
Open the panel grille, squeeze the clamps to quit the
grille from clamp.
Clamp Panel grille Clamp
