Gree GMV-160WL/C-T

GREE DC Inverter Multi VRF System II Service Manual
150
NO.
Name of Part
GMV-121WL/A-T
GMV-121WL/C-T
Product Code
CN850W0420
CN850W0640
Part Code
Quantity
15
Compressor Overload Protector(External)
'00183051
1
16
Electric Heater(Compressor)
'7651873215
1
17
Brushless DC Motor
'1570280000401
1
18
Axial Flow Fan
'10434100005
1
19
Diversion Circle
'10474100003
1
20
Cabinet
'01514100007P
1
21
Front Side Plate
'01314100044P
1
22
Handle
'26235253
1
23
Front Grill
'01572800003
1
24
Drainage hole Cap
'06813401
1
25
Chassis Sub-Assy
'017000000148P
1
26
Motor Support Sub-Assy
'01804100309
1
27
Clapboard Sub-Assy
'01244100020
1
28
Sensing Device
'322101002
1
29
Gas-liquid Separator
'07422809
1
30
Magnet Coil (electromagnetic valve)
'4304410018903
1
31
4-way Valve
'4300008201
1
32
Magnet Coil
'4304410018902
1
33
Compressor
'00205200003
1
34
Compressor Gasket
'76713066
1
35
Sensing Device
'322101032
1
36
Nozzle for Adding Freon
'06120014
1
37
Cut off Valve
'07334100016
1
38
Cut off Valve
'07130209
1
39
Strainer
'07212001
1
40
Bidirection Strainer
'07210044
1
41
Valve Support Assy
'01804100306
1
42
Nozzle for Adding Freon
6120012
1
43
Capillary Sub-Assy
'030006000255
1
44
Electromagnetic Valve
'43000054
1
45
Right Side Plate
'01314100046P
1
46
Rear Side Plate
'01314100045P
1
47
Silencer
'07444105
1
48
Pressure Protect Switch
'4602000913
1
49
Plate-type Heat Exchanger
'00904100003
1
50
Electric Expand Valve Fitting
'4304413205
1
51
Electric Expand Valve Fitting
'4304413220
1
52
Strainer
'07212121
1
53
Silencer
'07245012
1
54
Condenser Sub-Assy
'0115410001901
1
55
Rear Grill
'01574100010
1
