Gree GMV6 DC Inverter VRF Units Service Manual
2 Parameters
2.1 Parameters of Basic Modules
Model - GMV-224WM/G-X GMV-280WM/G-X
GMV-335WM/G-X GMV-400WM/G-X GMV-450WM/G-X
HP HP 8 10 12 14 16
Product Code - CN851W3030 CN851W3010 CN851W2820 CN851W2980 CN851W2990
Cooling capacity kW 22.4 28.0 33.5 40.0 45.0
Heating capacity kW 25.0 31.5 37.5 45.0 50.0
Pa 0/110 0/110 0/110 0/110 0/110
Noise (sound pressure
level)
dB(A) 56 57 59 59 60
Power -
Cooling power input kW 5.0 6.2 7.7 9.2 10.8
Heating power input kW 4.8 5.9 7.8 9.5 10.7
Cooling current input A 8.9 11.1 13.8 16.4 19.3
Heating current input A 8.6 10.5 13.9 17.0 19.1
Rated power input kW 12.87 13.15 13.50 18.18 18.74
Rated current A 23 23.5 24.1 32.50 33.5
Compressor type - Inverter scroll Inverter scroll Inverter scroll Inverter scroll Inverter scroll
Compressor function - EVI EVI EVI EVI EVI
Compressor quantity N 1 1 1 1 1
Refrigeration oil No. of
compressor
- FV68H FV68H FV68H FV68H FV68H
Refriger
ation oil
charge
Gross L 4.6 4.6 4.6 6.1 6.1
L 1.1 1.1 1.1 1.1 1.1
The others L 3.5 3.5 3.5 5 5
°C -5~52 -5~52 -5~52 -5~52 -5~52
°C -30~24 -30~24 -30~24 -30~24 -30~24
Refrigerant type - R410A R410A R410A R410A R410A
Refrigerant charge kg 5.5 5.5 5.7 7 7.5
unit 13 16 19 23 26
Gas pipe mm Φ19.05 Φ22.2 Φ25.4 Φ25.4 Φ28.6
Liquid pipe mm Φ9.52 Φ9.52 Φ12.7 Φ12.7 Φ12.7
Outline dimensions
(W × D × H)
mm 930×775×1690 930×775×1690 930×775×1690 1340×775×1690 1340×775×1690
Packing dimensions
(W × D × H)
mm 1000×830×1855 1000×830×1855 1000×830×1855 1400×830×1855 1400×830×1855
Net weight kg 215 215 220 290 290
Gross weight kg 225 225 230 305 305
Model - GMV-504WM/G-X GMV-560WM/G-X GMV-615WM/G-X GMV-680WM/G-X
HP HP 18 20 22 24
Product Code - CN851W2880 CN851W3000 CN851W3020 CN851W2890
Cooling capacity kW 50.4 56 61.5 68
Heating capacity kW 56.5 63 69 76.5
Pa 0/110 0/110 0/110 0/110
Noise (sound
pressure level)
dB(A) 61 62 63 64
Power -
Cooling power input kW 12.3 13.8 16.2 20.5
Heating power input kW 12.9 13.1 16.9 20.1
