GREE GMV5E DC INVERTER VRF UNITS SERVICE MANUAL
293
No.
Name of part
GMV-450WM/E-X
GMV-504WM/E-X
Product Code
CN851W1830
Product Code
CN851W2230
Part code
Quantity
Part code
Quantity
60
Main Board
30223000041
1
30223000041
1
61
Terminal Board
42018000026
1
42018000026
1
62
Terminal Board
42018000577
2
42018000577
2
63
Main Board
30223000039
2
30223000039
2
64
Radiator
49018000088
2
49018000088
2
65
Radiator
49018000080
2
49018000080
2
66
Electric Box Assy
01394100373
1
01394100373
1
No.
Name of part
GMV-560WM/E-X
GMV-615WM/E-X
Product Code
CN851W2240
Product Code
CN851W2220
Part code
Quantity
Part code
Quantity
1
Rear Grill
01574100002
2
01574100002
2
2
Coping
01264100006P
1
01264100006P
1
3
Diversion Circle
10474100002
2
10474100002
2
4
Axial Flow Fan
10434100002
2
10434100002
2
5
Fan Motor
15704124
2
15704124
2
6
Nozzle for Adding Freon
06120012
2
06120012
2
7
One way Valve
07335210
1
07335210
1
8
4-way Valve
43000412
1
43000412
1
9
Filter
07218603
1
07218603
1
10
Electromagnetic Valve
43000054
4
43000054
4
11
Strainer
07415200002
6
07415200002
6
12
Upper Cover Plate (back)
01264100005P
1
01264100005P
1
13
Rear Grill
016001500381
1
016001500381
1
14
Condenser Assy
01100250016201
1
01100250016201
1
15
One Way Valve
07333700032
2
07333700032
2
16
Gas-liquid Separator
07424138
1
07424138
1
17
Chassis Sub-assy
01194100070P
1
01194100070P
1
18
Left Side Plate
012055500022P
1
012055500022P
1
19
Plate-type Heat Exchanger
00904100004
1
00904100004
1
20
Electronic Expansion Valve
07334412
1
07334412
1
21
Dry Filter
07218769
1
07218769
1
22
Gas Tube Filter
072190511
2
072190511
2
23
Electronic Expansion Valve
07331139
1
07331139
1
24
Strainer
07210037
1
07210037
1
25
One way Valve
04324001
2
04324001
2
26
Discharge Charge Valve
07334100002
2
07334100002
2
27
Oil Separator
07424100023
2
07424100023
2
28
Cut off Valve
07130239
2
07130239
2
29
Cut off Valve
07334100053
1
07334100053
1
30
Cut off Valve
07334100011
1
07334100011
1
31
Cut off Valve
07334100014
1
07334100014
1
32
Pressure Protect Switch
4602000911
1
4602000911
1
33
Oil Separator
0742418601
1
0742418601
1
34
Compressor and Fittings
00204100008
2
00204100008
2
35
Reactor Sub-assy
01394100449
1
01394100449
1
36
Reactor
4313017403
2
4313017403
2
