GREE GMV5E DC INVERTER VRF UNITS SERVICE MANUAL
292
No.
Name of part
GMV-450WM/E-X
GMV-504WM/E-X
Product Code
CN851W1830
Product Code
CN851W2230
Part code
Quantity
Part code
Quantity
15
One Way Valve
07333700032
2
07333700032
2
16
Gas-liquid Separator
07424138
1
07424138
1
17
Chassis Sub-assy
01194100070P
1
01194100070P
1
18
Left Side Plate
012055500022P
1
012055500022P
1
19
Plate-type Heat Exchanger
00904100004
1
00904100004
1
20
Electronic Expansion Valve
07334412
1
07334412
1
21
Dry Filter
07218769
1
07218769
1
22
Gas Tube Filter
072190511
2
072190511
2
23
Electronic Expansion Valve
07331139
1
07331139
1
24
Strainer
07210037
1
07210037
1
25
One way Valve
04324001
2
04324001
2
26
Discharge Charge Valve
07334100002
2
07334100002
2
27
Oil Separator
07424100023
2
07424100023
2
28
Cut off Valve
07130239
2
07130239
2
29
Cut off Valve
07334100053
1
07334100053
1
30
Cut off Valve
07334100011
1
07334100011
1
31
Cut off Valve
07334100014
1
07334100014
1
32
Pressure Protect Switch
4602000911
1
4602000911
1
33
Oil Separator
0742418601
1
0742418601
1
34
Compressor and Fittings
00204100008
2
00204100008
2
35
Reactor Sub-assy
01394100449
1
01394100449
1
36
Reactor
4313017403
2
4313017403
2
37
Top Cover (front)
01264100004P
2
01264100004P
2
38
Left Front Panel
012062500040P
1
012062500040P
1
39
Handle
26904100016
1
26904100016
1
40
Electric expand valve fitting
4304413203
1
4304413203
1
41
Electric Expand Valve Fitting
4304413204
1
4304413204
1
42
Magnet Coil
4304000414
1
4304000414
1
43
Magnet Coil
4304000440
1
4304000440
1
44
Magnet Coil
4304000423
1
4304000423
1
45
Magnet Coil
4300040030
1
4300040030
1
46
Magnet Coil
4304000420
1
4304000420
1
47
Pressure Sensor
32218000009
1
32218000009
1
48
Pressure sensor
32218000008
1
32218000008
1
49
Electric
Heater(Compressor)
7651540713
1
7651540713
1
50
Electric
Heater(Compressor)
7651540714
1
7651540714
1
51
Electrical
Heater(Compressor)
7651873209
1
7651873209
1
52
Sensor Sub-assy
39008000102G
1
39008000102G
1
53
Pressure Protect Switch
4602000912
1
4602000912
1
54
Right Side Plate
012056500021P
1
012056500021P
1
55
Electric Box Assy
01394100426
1
01394100426
1
56
Radiator
49018000001
2
49018000001
2
57
Main Board
30223000032
2
30223000032
2
58
Filter Board
30223000025
2
30223000025
2
59
Terminal Board
42010247
1
42010247
1
