Gree GMV-450WM/B-X Service Manual

GMV5 DC INVERTER VRF UNITS SERVICE MANUAL
222
Parts List:
No.
Name of part
GMV-335WM/B-X
Product Code
CN851W1300
Part code
Quantity
1
Rear Grill
01574100002
2
2
Top Cover
01264100006P
1
3
Diversion Circle
10474100002
2
4
Motor for Axial Fan Assy
15404100018
2
5
Axial Flow Fan
10434100002
1
6
Fan Motor
15704124
1
7
Gas By-pass sub- assy
04634100012
1
8
Magnet Coil
4304000420
1
9
Filter
07415200002
1
10
Electromagnetic Valve
43000054
1
11
Rear Top Cover
01264100005P
1
12
Rear Grill
01574100001
1
13
Condenser Assy
01124100096
1
14
Low Pressure Survey Valve Sub-assy
07334100010
1
15
Cut off Valve
07130239
1
16
Throttle Assy
05374100012
1
17
Electric Expansion Valve Sub-Assy
43044100012
1
18
Electric expand valve fitting
4304413203
1
19
Electronic Expansion Valve
07331139
1
20
Discharge Charge Valve
07334100002
2
21
One way Valve
04324001
2
22
Electric expand valve fitting
4304413204
1
23
Electronic Expansion Valve
07334412
1
24
Bidirection Strainer
07210044
1
25
Dry Filter Sub-Assy
00904100012
1
26
Dry Filter Sub-Assy
07314100002
1
27
Gas Tube Filter
072190511
2
28
Dry Filter
07218769
1
29
Gas-liquid Separator
07424138
1
30
Oil Separator
0742418601
1
31
Electric Heater(Compressor)
7651873209
1
32
Right Side Plate
01314713P
1
33
Chassis Sub-assy
01194100069P
1
34
Base Frame Assy
01284100002
1
35
Liquid Valve Sub-Assy
07304100009
1
36
Cut off Valve
07334100013
1
37
Valve
07304100007
1
38
Cut off Valve
07334100011
1
39
Gas Hose Sub-Assy
04574100027
1
40
Cut off Valve
07334100014
1
41
Compressor Gasket
70410226
4
42
Compressor
00204100004
1
43
Electric Heater(Compressor)
7651540713
1
44
Oil Equalizing Pipe Sub-Assy
04224100054
1
