Gree GMV-450WM/B-X Service Manual

GMV5 DC INVERTER VRF UNITS SERVICE MANUAL
223
45
Magnet Coil
4304000440
1
46
Oil Equalizing Pipe Sub-Assy
04224100059
1
47
Magnet Coil
4304000423
1
48
Left Front Panel
01544100003P
1
49
Right Front Panel
01544100005P
1
50
Handle
26904100016
2
51
Front Top Cover
01264100004P
2
52
Sensor Sub-assy
39004100008G
1
53
Pressure Sensor
32218000009
1
54
Pressure Sensor
32218000008
1
55
Discharge Tube Sub-assy
04534100052
1
56
Oil Separator
07424100023
1
57
Pressure Protect Switch
4602000910
1
58
Left Side Plate
01314712P
1
59
4-Way Valve Sub-Assy
04044100003
1
60
Filter
07218603
1
61
Magnet Coil
4300040030
1
62
4-way Valve
43000339
1
63
One way Valve
07335210
1
64
Nozzle for Adding Freon
06120012
2
65
Electric Box Assy
01394100192
1
66
Filter Board
30228000015
1
67
Reactor
43138000034
1
68
Rectifier
46010604
1
69
Main Board
30228000010
1
70
Main Board
30229009
1
71
Radiator
49018000002
1
72
Radiator
49018000001
2
73
Terminal Board
42010247
1
74
Main Board
30223000005
1
75
Terminal Board
42018000026
1
Above data is subject to change without notice,pls reference the SP in global service website.
