Gree GMV-60WL/C-T Service Manual

GREE DC Inverter Side Discharge VRF Ⅱ for North America
125
4.2.2 GMV-36WL/A-T(U), GMV-48WL/A-T(U), GMV-60WL/A-T(U)
GMV-36WL/C-T(U), GMV-48WL/C-T(U), GMV-60WL/C-T(U) , series unit
Removal operation for panel
Remark: Before removing the panel, please make sure that the unit is disconected with the power
Process
Operation Instruction
1.Remove top
cover
Loose the screws
fixing the top cover
with screwdriver
Hold the top cover
upwards and then put
it on the floor flatly
2. Remove front
side plate
sub-assy
Loose the screw
fixing the front side
plate with screwdriver
Hold the front side
plate upwards and
then put it on the floor
flatly
3. Remove front
panel and grille
Loose the screws
fixing the front panel
and grille with
screwdriver
Put the front panel
and grille on the floor
flatly
