GREE DC Inverter Multi VRF System II Service Manual
127
Removal operation for panel
Remark: Before removing the panel, please make sure that the unit is disconected with the power
Process
Operation Instruction
2. Remove front
side plate
● Loose the screw fixing the front
side plate with screwdriver
● Hold the front side plate
upwards and then put it on the
floor flatly
3. Remove rear
side plate
● Loose the screws fixing the front
panel and grille with screwdriver
● Put the front panel and grille on
the floor flatly
Removal operation for blade
Remark: Before removing the motor, please make sure that the unit is disconnected with the power.
Process
Operation Instruction
1. Remove grille
● Loose screws fixi
ng the panel
with screwdriver
● Then remove the grille
