Gree GMV-N140U/A-T Service Manual

GREE GMV5 INDOOR UNIT SERVICE MANUAL
239
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND22SPL/B1-T
CM810N1580
GMV-ND25SPL/B1-T
CM810N1570
GMV-ND28SPL/B1-T
CM810N1340
GMV-ND32SPL/B1-T
CM810N1560
GMV-ND36SPL/B1-T
CM810N1330
Part code
Quantity
6
Cover Plate(Air return)
01265200057
1
7
Bottom Cover Plate Assy
01264100102
1
8
Hook
02112446
2
9
Left Side Plate Assy
01314100136
1
10
Electric Box Assy
01394100602
1
11
Terminal Board
4201800002601
1
12
Terminal Board
42011106
1
13
Main Board
30226000029
1
14
Main Board 2
30227000010
1
15
Water Pump
4313822001
1
16
Pump Drainpipe
26904100172
1
17
Water Level Switch
4501270301
1
18
Electric Expand Valve Fitting
4304413215
1
19
Electronic Expansion Valve
07334463
1
20
Strainer
07213050
1
21
Strainer
0721200102
1
23
Air Outlet Frame Assy
01374100090
1
24
Evaporator Assy
01024100202
1
25
Water Tray Assy
01285200020
1
26
Top Cover Board Assy
01265200066
1
27
Right Side Plate Assy
01315200053
1
28
Sensor Sub-assy
39004168G
1
29
Display Board
30296000026
1
Above data is subject to change without notice, pls reference the SP in global service website.
