Gree GMV-ND22PHS/B-T User Manual

Multi Variable Air Conditioners Ducted Type Indoor Unit
4
No.
Name
Appearance
Q'ty
Usage
4
M10X8 Nut with Washer
4
To be used together with the hanger bolt
for installing the unit.
5
M10 Nut (M10X8.4 Nut)
4
To be used together with the hanger bolt
for installing the unit.
6
M10 Washer (Spring Washer
M10X2.6)
4
To be used together with the hanger bolt
for installing the unit.
7
Insulation
1
To insulate the gas pipe
8
Insulation
1
To insulate the liquid pipe
9
Sponge
2
To insulate the drain pipe
10
Fastener
8
To fasten the sponge
Note: User can purchase remote controller and receiver otherwise by himself.
3.2 Location for Installation
(1) The appliance shall not be installed in the laundry.
(2) The top holder must be strong enough to support unit’s weight.
(3) Drain pipe can drain water out easily.
(4) There is no obstacle at inlet or outlet. Please ensure good air circulation.
(5) In order to make sure the space for maintenance, please install the indoor unit according
to the dimension described below.
(6) Keep the unit away from heating source, inflammable gas or smoke.
(7) This is a concealed ceiling type unit.
(8) Indoor unit, outdoor unit, power cord and electric wire should stay at least 1m from the TV
set and radio. Otherwise, these electrical appliances may have image interference and
noise. (Even if the distance is 1m, when there is strong electric wave, noise may still
occur.)
