Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit
3
Any personal injury or property loss caused by improper installation, improper debug,
unnecessary repair or not following the instructions of this manual should not be the
responsibility of Gree Electric Appliances, Inc. of Zhuhai.
This Multi VRF System shall only be connected to an appliance suitable for the same
refrigerant.
All units in Manual Cover is a partial unit, complying with partial unit of IEC 60335-2-
40:2018, and must only be connected to other units that have been confirmed as complying to
corresponding partial unit requirements of this international standard.
The electrical interface shall comply with electrical security requirement, current shall be
referred to the table of “Dimension of power cord and capacity of air switch” in Section 3.4, and
safety class of construction is I.
Correct Disposal of this Product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To
return your used device, please use the return and collection systems or
contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
2 Product Introduction
2.1 Names of Key Components
Fig.2.1
2.2 Rated Working Condition
Test condition
Indoor Side Condition Outdoor Side Condition
Dry Bulb Temp℃ Wet Bulb Temp℃ Dry Bulb Temp℃ Wet Bulb Temp℃
Rated Cooling 27 19 35 24
Rated Heating 20 15 7
To Next Page
