Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit
4
3 Preparations for Installation
Note:
This picture is for reference only, please refer to the actual product; the unit of
dimension is mm.
3.1 Standard Fittings
Use the following provided accessories according to the requirement.
No. Name Appearance Q’ty Usage
1
Remote
Controller
1+2 To control the indoor unit
2 Special Nut
2 GMV-ND28~140ZD/B-T
1 GMV-ND160ZD/B-T
3 Corrugated Pipe
1 GMV-ND160ZD/B-T
4
M10×8 Nut with
Washer
8
To be used together with the
suspension bolt for installing the
unit.
5 Insulation
2 To insulate the gas/liquid pipe
6
Paper Pattern for
Installation
— 1
Locate the drill hole on ceiling or
wall
7 Fastener
4 To fasten the sponge
To Next Page
