Gree GMV-ND36ZD/A-T

GREE GMV5 INDOOR UNIT SERVICE MANUAL
189
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND90PHS/A-T
CM800N3550
GMV-ND100PHS/A-T
CM800N3650
GMV-ND112PHS/A-T
CM800N3660
GMV-ND125PHS/A-T
CM800N3670
GMV-ND140PHS/A-T
CM800N3680
Part code
Quantity
15
Right Side Plate Sub-Assy
01315200100
1
16
Electric Box Assy
01394100255
1
17
Main Board
30226000027
1
18
Terminal Board
42011154
1
19
Terminal Board
4201800002601
1
20
Inductance
43128000014
1
21
Electric Box Cover
01424100078
1
22
Blower Mounting Plate Sub-Assy
01325200044
1
23
Volute casing(Upper)
26904100051
2
24
Centrifugal Fan
10424100001
2
25
Brushless DC Motor
15709400006
1
26
Volute casing(Lower)
26904100052
2
27
Top Cover Board Assy
01264100039
1
28
Hook
02112466
4
29
Left Side Plate Assy
01315306
1
30
Sensor Sub-assy
39004169G
1
31
Dsplay Board
30296000040
1
Above data is subject to change without notice, pls reference the SP in global service website.
