0 57 INSTALLATION
GMV5 COMPACT MULTI VRF UNIT
SERVICE MANUAL
he discharged air of outdoor unit will not flow back and there is sufficient space around the unit for
maintenance;
he installation site must be well ventilated to ensure sufficient air intake and discharge. Make sure there is no
obstacle at the air
inlet and air outlet. If there is any obstacle, please remove it;
he installation site shall be able to withstand the weight of outdoor unit and capable for soundproof and
vibration. The air outlet
and noise of unit will not affect neighbors;
he hanging of outdoor unit must use appointed hanging hole. Pay attention to protect the unit during hanging
and installation.
Prohibit hitting the sheet metal to avoid rust in the future.
void direct sunlight;
he rain and condensation water can be drained out smoothly;
he outdoor unit will not be embedded by the snow and not affected by garbage and oil smog;
he installation of outdoor unit shall adopt rubber damping pad or spring damper to reduce noise and
vibration;
he installation dimension shall accord with the installation requirement of this manual and the outdoor unit
must be fixed at the installation site;
he installation shall be done by professional technicians
4.5 Fixing and damping of unit
The outdoor unit shall be fixed with 4 M12 bolts and closely contacted with the foundation. Otherwise, big
vibration and noise will be caused.
The outdoor unit shall be fixed firmly. The rubber board with thickness over 20mm or corrugated rubber
damping pad shall be applied between the unit and foundation.
4.6 Physical Dimension of the Outdoor Unit and Mounting Hole
GMV-224WL/A-X, GMV-250WL/A-X, GMV-280WL/A-X,
1) Outdoor unit physical dimension (mm)
To Next Page
