Gree GMV5 Compact Series Service Manual

0 61 INSTALLATION
GMV5 COMPACT MULTI VRF UNIT
SERVICE MANUAL
H
> 20
C eiling
W a ll
W a ll
Flo o r
1500
GMV-ND28T/A-T, GMV-ND36T/A-T, GMV-ND45T/A-T, GMV-ND50T/A-T (mm)
A
B
C
D
E
G
H
950
890
840
680
780
65
210
GMV-ND56T/A-T, GMV-ND63T/A-T, GMV-ND71T/A-T, GMV-ND80T/A-T (mm)
A
B
C
D
E
G
H
950
890
840
680
780
65
260
GMV-ND90T/A-T, GMV-ND100T/A-T, GMV-ND112T/A-T, GMV-ND125T/A-T, GMV-ND140T/A-T (mm)
A
B
C
D
E
G
H
950
890
840
680
780
65
340
GMV-ND160T/A-T (mm)
A
B
C
D
E
G
H
1040
975
910
787
840
65
315
5.1.2 1-way cassette type
① Outline dimension: (mm)
