INSTALLATION 0620
GMV5 COMPACT MULTI VRF UNIT
SERVICE MANUAL
1200(decorative panel
)
987(main body)
1027(distance of lifting screw)
1115( )ceiling outlet
261(distance of lifting screw)
385(main body)
415(ceilding outlet)
456(decorative panel)
② Istallation dimensions: (mm)
≥1500
≥1500
≥1800
23
141
178
≥197
Wall
Ceiling
Floor
Wall
≥20
5.2 Installation of duct type indoor unit
5.2.1 Low static pressure duct type
① Outline dimensions
