0 69 INSTALLATION
GMV5 COMPACT MULTI VRF UNIT
SERVICE MANUAL
W D
H
GMV-N22G/A3A-K, GMV-N28G/A3A-K (mm)
W
H
D
843
275
180
GMV-N36G/A3A-K, GMV-N45G/A3A-K, GMV-N50G/A3A-K (mm)
W
H
D
940
298
200
GMV-N56G/A3A-K, GMV-N63G/A3A-K, GMV-N71G/A3A-K (mm)
W
H
D
1008
319
221
② Installation space (mm)
5.5 Installation notice
(1) Installation dimension (refer to the outline dimension in the figure).
(2) Make sure the top hanging rod, ceiling and building structure have sufficient strength to withstand the weight of
