3. Fix the protective grille on joint B+C with 2 screws.
4. Fix the support on the outer side of window frame with 2 nuts, spring washer,
washer and bolt.
5. Fix the support on the outer side of window frame with 2 nuts, spring washer,
washer and bolt.
NOTE: protective grille, support, rain shield, nut, bolt, spring washer and washer
are optional accessories; some models are without these accessories.
Window frame
Joint B+C
Screws
Bolt
Washer
Spring washer
Spring washer
Nut
Washer
Screws
Nut
Rain shield
Protective grille
