9
Technical Information
5. Electrical Part
5.1 Wiring Diagram
● Indoor Unit
●Instruction
Symbol Symbol Color Symbol Symbol Color Symbol Name
WH White GN Green COMP Compressor
YE Yellow BN Brown Grounding wire
RD Red BU Blue / /
YEGN Yellow/Green BK Black / /
VT Violet OG Orange / /
600007064533
AP2
LAMP
MODULE
OUTDOOR UNIT
AP1
DISPLAY
CN1
DISP1
BOARD
RT1
ROOM
SENSOR
ROOM
AP3
WIFI
MODULE
WIFI
OPTIONAL
CONNECTOR
CONNECTOR
