Gree GRH085DB-K6NA1A

45
Installation and Maintenance
Screws
Screws
Main Board
Screw
Water ba󰀪e (4-way valve)
Tube Clip
Step Procedure
7.Remove electric box assy
Lift the mainboard, disconnect each wiring terminal on
the mainboard; Remove screws xing the electric box
assy, remove the ground screw on the condenser and
then lift the electric box assy to remove it.
8.Remove water ba󰀪e
Remove screw xing the water ba󰀪e (4-way valve);
remove screw xing the tube clip, then remove the
water ba󰀪e (4-way valve).
