Removal of fan and motor
Note: Before removing the motor, power must be cut off.
Step Picture Work instruction
3. Remove the water tray.
Loosen the screws in the 4
corners and then remove
the water tray.
4. Remove the fan.
Use a screwdriver to remove
the clamping band of motor.
Then remove the fan.
