Gree GWC09NA-D3NNB1A/I


5HPRYDO3URFHGXUH
2
1
2
3
Remove the electric box cover, seperate
it from the front case.
electric box cover
screw
5. Remove front case
Open the screw cap on the front case.
Remove the screws fixing the front case.
Loosen the six clasps of the front case.
clasp
Remove the front case to seperate it with
bottom assembly.
front case
left
middle
right
