Gree GWC09NA-D3NNB1A/I


5HPRYDO3URFHGXUH
5HPRYDO3URFHGXUHRI2XWGRRU8QLW
Warning Be sure to wait for a minimum of 10 minutes after
turning off all power supplies before disassembly.
b
handle
a
1. Remove big handle
Before disassembly.
Remove the screw fixing the big handle.
Remove the big handle.
Remove the 3 screws connecting the top
panel with the front panel and the right side
panel. Remove the top cover.
2. Remove top panel
top panel
.
127(7DNHKHDWSXPSIRUH[DPSOH
