5HPRYDO3URFHGXUH
.
Warning Be sure to wait for a minimum of 10 minutes after
turning off all power supplies before disassembly.
1. Before disassembly
2. Remove big handle
Remove the connection screw fixing the big handle
and then remove the handle.
3. Remove top panel
Remove connection screws connecting the top
panel with the front panel and the right side plate,
and then remove the top panel.
big handle
top panel
127(7DNHKHDWSXPSIRUH[DPSOH
To Next Page
