Gree GWC09NA-D3NNB1A/I


5HPRYDO3URFHGXUH
auxiliary piping
heat
exchanger
step motor
1
2
3
1
9. Remove evaporator
Remove the 3 screws at the joint of the
evaporator and rear case.
screw
Adjust slightly the pipe on the evaporator to
separate the pipe with the evaporator.
Remove the evaporator to separate the evaporator
with rear case assy.
10. Remove motor and cross flow blade
Remove screws of step motor and then remove
the step motor.
