Gree GWC12KF-K3DNA5A Service Manual

8
Specifications
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Model of Outdoor Unit GWH09KF-K3DNA5A/O GWH12KF-K3DNA5A/O
Compressor
Manufacturer/Trademark
Daikin Compressor Industries
/daikin
Daikin Compressor
Industries/daikin
Compressor Model 1YC23AEXD 1YC23AEXD
Compressor Oil DAPHEN FVC50K DAPHEN FVC50K
Compressor Type Rotary Rotary
L.R.A. A 4 4
Compressor RLA A 4 4
Compressor Power Input W 600W 600W
Overload Protector CS-7SA CS-7SA
Throttling Method Capillary Capillary
Operation temp
℃
16
～
30 16
～
30
Ambient temp (cooling)
℃
10
～
48 10
～
48
Ambient temp (heating)
℃
-15
～
24 -15
～
24
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-fin Gap mm 1-1.4 2-1.4
Coil Length (LXDXW) mm 647X528X19.05 647X528X38.1
Fan Motor Speed rpm 930 930
Output of Fan Motor W 30 30
Fan Motor RLA A 0.236 0.236
Fan Motor Capacitor μF2 2
Air Flow Volume of Outdoor Unit
m
3
/h
1600 1600
Fan Type Axial-flow Axial-flow
Fan Diameter mm 370 370
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 3.8 3.8
Permissible Excessive Operating
Pressure for the Suction Side
MPa 1.2 1.2
Sound Pressure Level (H/M/L) dB (A) 51/-/- 53/-/-
Sound Power Level (H/M/L) dB (A) 61/-/- 63/-/-
Dimension (WXHXD) mm 658X550X275 658X550X275
Dimension of Carton Box (L/W/H) mm 768X345X577 768X345X577
Dimension of Package (L/W/H) mm 771X348X592 771X348X592
Net Weight kg 28 30
Gross Weight kg 32 34
Refrigerant R410A R410A
Refrigerant Charge kg 0.74 1
Length m 5 5
Gas Additional Charge g/m 30 20
Outer Diameter Liquid Pipe mm Φ6 Φ6
Outer Diameter Gas Pipe mm Φ9.52 Φ9.52
Max Distance Height m 10 10
Max Distance Length m 15 20
Outdoor Unit
Connection
Pipe
