Gree GWC12KF-K3DNA5A Service Manual

80
10.2 Removal Procedure of Outdoor Unit
Warning Be sure to wait 10 minutes or more after turning
off all power supplies before disassembling work.
1. Features
The stop valve cover has 6
hooks.
Loosen the screw of the
stop valve cover.
Pull down the stop valve
cover and remove
it.
1
Loosen the 3 screws
(front, right, left) and lift
the top panel.
1
Handle
Stop
valve
cover
2. Removing air filters
Top panel
Removal Procedure
