18
5.3 Printed Circuit Board
TOP VIEW
BOTTOM VIEW
Schematic Diagram
Interface of input live wire
Interface of input null wire
Interface of live wire
of cold-plasma
Interface of null wire of cold-plasma
Interface of indoor fan
Interface for feedback of indoor fan
Interface of pipe temp sensor
Interface of ambient temp sensor
Interface of communication wire
Interface of input live wire
Interface of motor
Interface of capacitor of fan
Interface of display device
