7
Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor Unit
Model of Outdoor Unit GWC09AFC-D3DNA1A/O
Outdoor Unit Product Code CB348W03300
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO., LTD
Compressor Model QXF-A079zE190A
Compressor Oil FW68DA
Compressor Type Rotary
Compressor L.R.A. A /
Compressor RLA 4.6
Compressor Power Input W 790
Overload Protector HPC115/95U1/KSD115ºC
Throttling Method Electron expansion valve
Operation temp ºF 61~86
Ambient temp (cooling) ºF -4~115
Ambient temp (heating) ºF /
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/8
Rows-n Gap inch 2-1/16
Coil Length (LXDXW) inch 28X3/4X20
Fan Motor Speed rpm 900
Output of Fan Motor W 30
Fan Motor RLA A 0.36
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit CFM 942
Fan Type Axial-ow
Fan Diameter inch Φ15 3/4
Defrosting Method /
Climate Type T1
Isolation I
Moisture Protection IPX4
Design Pressure(High) PSIG 550
Design Pressure(Low) PSIG 240
Sound Pressure Level (H/M/L) dB (A) 49/-/-
Sound Power Level (H/M/L) dB (A) 59/-/-
Dimension (WXHXD) inch 30 9/16X21 1/4X12 5/8
Dimension of Carton Box (LXWXH) inch 32 9/32X13 63/64X22 27/32
Dimension of Package (LXWXH) inch 32 13/32X14 3/32X23 27/64
Net Weight Ib 63.9
Gross Weight Ib 69.5
Refrigerant R410A
Refrigerant Charge oz 28.2
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.2
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 3/8
Max Distance Height ft 40
Max Distance Length ft 65.6
Note:The connection pipe applies metric diameter.
