Technical Information
Service Manual
Model GWH09QC-D3DND8A
Product Code CB459006900
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 9000
Heating Capacity Btu/h 10000
Cooling Power Input W 700
Heating Power Input W 780
Cooling Power Current A 3.25
Heating Power Current A 3.75
Rated Input W 1450
Rated Current A 5.95
Air Flow Volume(SH/H/M/L) CFM 371/341/294/235
Dehumidifying Volume Pint/h 2.96
EER (Btu/h)/W 12.8
COP (Btu/h)/W 12.8
SEER 21
HSPF 9
Application Area yd
2
14.4-21.5
Indoor Unit
Model of indoor unit GWH09QC-D3DND8A/I
Indoor Unit Product Code CB459N06900
Fan Type Cross-ow
Diameter Length(DXL) inch Φ3 55/64X25
Fan Motor Cooling Speed (SH/H/M/L/SL) r/min 1350/1200/1050/850/-
Fan Motor Heating Speed (SH/H/M/L/SL) r/min 1300/1150/1000/900/-
Output of Fan Motor W 20
Fan Motor RLA A 0.31
Fan Motor Capacitor μF 1.5
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16
Row-n Gap inch 2-1/16
Coil Length (LXDXW) inch 25X57/64X12 3/64
Swing Motor Model MP24BA
Output of Swing Motor W 1.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L/SL) dB (A)
Cooling:42/39/34/29/-
Heating:42/39/34/31/-
Sound Power Level (SH/H/M/L/SL) dB (A)
Cooling:52/49/44/39/-
Heating:52/49/44/41/-
Dimension (WXHXD) inch 33 1/4X11 3/8X8 1/4
Dimension of Carton Box (LXWXH) inch 36 1/8X11X14 5/16
Dimension of Package (LXWXH) inch 36 1/4X11X15
Net Weight
Ib 23.2
Gross Weight Ib 27.6
