NO.
Description
Part Code
Qty
GWH09QB-D3DNC6L/O GWH12QC-D3DNC6L/O
Product Code CB443W04600 CB443W04700
1 Front Grill 01473012 01473012 1
2 Front Panel Assy 0153304804 0153304804 1
3 Axial Flow Fan 10333004 10333004 1
4 Chassis Sub-assy 017000000133P 017000000126P 1
5 Clapboard Sub-Assy 0123338502 0123338502 1
6 Drainage Connecter 06123401 06123401 1
7 Compressor Gasket 76710287 76710287 3
8 4-Way Valve Assy 030152000171 030152000094 1
9 Valve Support 0171314201P 0171314201P 1
10 Cut off Valve Assy 07133474 07133474 1
11 Valve 07100003 07130239 1
12 Valve Support Block 26113017 26113017 2
13 Cover of Pass Wire 01413069 01413069 1
14 Right Side Plate Assy 013030713 013030713 1
15 Cable Cross Plate 2 02123014P 02123014P 1
16 Magnet Coil 4300040050 4300040050 1
17 Electric Expansion Valve Sub-Assy 030026000197 030026000192 1
18 Rear Grill 01473009 01473009 1
19 Electric Box 20113034 20113034 1
20 Main Board 300027000355 300027000359 1
21 Reactor 43130184 43130184 1
22 Electric Box Assy 100002001956 100002001959 1
23 Terminal Board 42010313 42010313 1
24 Wire Clamp 71010003 71010003 1
25 Top Cover Sub-Assy 000051060006 000051060006 1
26 Condenser Assy 011002000508 011002000492 1
27 Motor Support 01703104 0170310401 1
28 Fan Motor 1501308507 1501308507 1
29 Compressor Overload Protector(External) 00183032 00180030 1
30 Compressor and Fittings 009001000181 009001000181 1
31 Small Handle 26233100 26233100 1
32 Temperature Sensor 3900030805 3900030805 1
33 valve cover 2012300101 2012300101 1
